Brocade
The Brocade application normalizes Brocade events. You can further customize the searches to perform in-depth analysis.
Package Details
The application consists of the following components:
-
Normalization Packages
- LP_Brocade
- LP_Brocade SAN FC Switch
Enhancement
A minor update has been done in the application’s normalizer for better signature handling.
Installation
Follow these steps to install the Brocade v5.0.1 application:
- Download the Brocade package from the Download section above.
- Add Brocade as the required device in LogPoint.
- Create a collection policy with the Syslog collector and appropriate processing policy.
- Assign the policy to the device.
Supported Devices
The supported devices of Brocade with LogPoint in this configuration are:
-
Fabric OS v8.x, v7.x, 7.4.1b.
-
Brocade 6510 (HPE SN6000B)
-
Brocade 5480
-
Brocade 5100
-
Brocade 300
Log Format
Expected Log Format
- Syslog
Log Sample
<190>raslogd: 2012/07/06-08:02:15, [SEC-1193], 520, WWN xx:xx:xx:xx:xx:xx:xx:xx, INFO, saxxxx03, Security violation: Login failure attempt via HTTP. IP Addr: 1.1.1.1
To export data to LogPoint, use Syslog collector on port 514 on the LogPoint server.
Package Details
The application consists of the following components:
-
Normalization Packages
- LP_Brocade
- LP_Brocade SAN FC Switch
Enhancement
A minor update has been done in the application’s normalizer for better signature handling.
Installation
Follow these steps to install the Brocade v3.2.0 application:
- Download the Brocade package from the Download section above.
- Add Brocade as the required device in LogPoint.
- Create a collection policy with the Syslog collector and appropriate processing policy.
- Assign the policy to the device.
Supported Devices
The supported devices of Brocade with LogPoint in this configuration are:
-
Fabric OS v8.x, v7.x, 7.4.1b.
-
Brocade 6510 (HPE SN6000B)
-
Brocade 5480
-
Brocade 5100
-
Brocade 300
Log Format
Expected Log Format
- Syslog
Log Sample
<190>raslogd: 2012/07/06-08:02:15, [SEC-1193], 520, WWN xx:xx:xx:xx:xx:xx:xx:xx, INFO, saxxxx03, Security violation: Login failure attempt via HTTP. IP Addr: 1.1.1.1
To export data to LogPoint, use Syslog collector on port 514 on the LogPoint server.
Support
If you have any queries or require assistance, please feel free to contact our support team:
Email: servicedesk@logpoint.com
Phone: +45 7060 6100
