Mitel Fetcher
Mitel Fetcher fetches the SMDR (Station Messaging Detail Record) logs from Mitel using port 1752.
Package Details
Mitel Fetcher Components
-
Fetcher
- MitelFetcher
-
Compiled Normalizer
- MitelCompiledNormalizer
-
Log Source Template
- Mitel
Enhancement
|
Description |
Issue ID |
Reference ID |
|---|---|---|
|
You can now monitor SMDR (Station Messaging Detail Record) logs with color-coded indicators and set an inactivity threshold to determine when to mark the log source inactive. |
LP-62697 |
- |
Bug Fix
|
Description |
Issue ID |
Reference ID |
|---|---|---|
| In certain older base ISO versions, upgrading to Logpoint 7.5.0 or later displayed config generation error during installation. However, after installation, log collection was not affected. |
PLUG-15825 |
- |
Past Releases
Mitel Fetcher v6.0.0
Enhancements
Mitel Fetcher v5.0.0
General Description
The MitelFetcher application enables you to fetch and analyze logs from the Mitel server.
Release Details
|
Fields |
Details |
|---|---|
|
Name |
MitelFetcher |
|
Version |
5.0.0 |
|
Supported On |
LogPoint v6.7.0 or later |
|
Release Date |
2020-02-26 |
| Documentation | Mitel Fetcher |
| Download | MitelFetcher_5.0.0.pak |
| SHA256 |
781063459fd2505cd4ef59f427b508787a14fa1427cf2f90941dea1ee3b036c6 |
Package Details
The application package consists of the following components:
-
Fetcher
- MitelFetcher
Enhancement
The application has been updated to comply with LogPoint v6.7.0.
Installation
Follow these steps to install the MitelFetcher v5.0.0 application:
- Download the MitelFetcher_5.0.0 file provided in the Download section above.
- Extract the zip file to obtain the MitelFetcher_5.0.0.pak file.
- Install the application by importing the pak file to LogPoint under Settings >> System >> Applications.
- Add a required device in LogPoint.
- Click the Add collectors/fetchers icon under the Actions column.
- Click Mitel Fetcher.
-
In the Mitel Fetcher panel:
- Select a Parser.
- Select a Processing Policy.
- Select the Charset.
- Enter the Port of the Mitel server.
- Click Submit.
Verification
Use the following search command to access the logs fetched by the MitelFetcher application:
col_type = mitel
Support
If you have any questions or require assistance, create a support ticket.
