General Description
The Free Radius application normalizes Free Radius events and enables you to analyze the data using the pre-set dashboard views. You can further customize the dashboard and searches to perform in-depth analysis.
Release Details
|
Fields |
Details |
|---|---|
|
Version |
5.0.1 |
|
Release Date |
2020-05-14 |
| Document Date |
2020-05-14 |
|
Name |
Free Radius |
|
Supported On |
LogPoint v6.7.0 and later |
| Download | |
| SHA256 |
bff8b447ce9d19d13937d575a2d3466e7d37dee771ac33ceee728261798b3fca |
Package Details
The application consists of the following components:
- Dashboard Package
- LP_FreeRadius
- Normalization Packages
- LP_FreeRadius Server
- LP_FreeRadius WLAN
- LP_FreeRadius VPN
- Compiled Normalizer
- FreeRadiusCompiledNormalizer
Enhancement
A minor update has been done in the application’s normalizer for better signature handling.
Installation
Follow these steps to install the Free Radius v5.0.1 application:
- Download the Free Radius package from the Download section above.
- Add Free Radius as the required device in LogPoint.
- Create a collection policy with the Syslog collector and appropriate processing policy.
- Assign the policy to the device.
- Add the dashboard.
Screenshot
Supported Devices
The supported devices of Free Radius with LogPoint in this configuration are:
- Free Radius VPN
- Free Radius Server
- Free Radius WLAN
Log Format
Expected Log Format
Key = Value pair space-separated
Log Samples
<139>Sat Jun 1 04:02:21 2013 : Auth: Login incorrect (rlm_ldap: Bind as user failed): [tantom] (from client vpn1-gw port 688128 cli 1.1.1.1)
tantom -> johndoe
<139>Fri Sep 11 13:13:34 2015 User-Name = "tobper" NAS-Port = 52908032 Service-Type = Framed-User Framed-Protocol = PPP Framed-IP-Address = 1.1.1.1 Class = 0x4f553d697463 Called-Station-Id = "1.1.1.2" Calling-Station-Id = "1.1.1.3" Acct-Status-Type = Start Acct-Delay-Time = 0 Acct-Session-Id = "AF71C8F7" Acct-Authentic = RADIUS NAS-Port-Type = Virtual Tunnel-Client-Endpoint:0 = "1.1.1.4" Vendor-3076-Attr-146 = 0x44656661756c7457454256504e47726f7570 Vendor-3076-Attr-150 = 0x00000002 Vendor-3076-Attr-151 = 0x00000001 Vendor-3076-Attr-152 = 0x00000003 NAS-IP-Address = 1.1.1.5 Client-IP-Address = 1.1.1.6 Acct-Unique-Session-Id = "b06a4bccebe7c953" Stripped-User-Name = "tobper" Realm = "NULL" Timestamp = 1441970014
tobper -> johndoe
To export data to LogPoint, use Syslog collector on port 514 on the LogPoint server.
Release Details
|
Fields |
Details |
|---|---|
|
Name |
Free Radius |
|
Version |
3.3.0 |
|
Supported On |
LogPoint v6.0.0 to v6.6.6 |
|
Release Date |
2020-05-14 |
| Document Date |
2020-05-14 |
| Download | |
| SHA256 |
633440fca6c196827a097977f9c07a42857add6c5440c9dae23adbe8050733ef |
Package Details
The application consists of the following components:
- Dashboard Package
- LP_FreeRadius
- Normalization Packages
- LP_FreeRadius Server
- LP_FreeRadius WLAN
- LP_FreeRadius VPN
- Compiled Normalizer
- FreeRadiusCompiledNormalizer
Enhancement
A minor update has been done in the application’s normalizer for better signature handling.
Installation
Follow these steps to install the Free Radius v3.3.0 application:
- Download the Free Radius package from the Download section above.
- Add Free Radius as the required device in LogPoint.
- Create a collection policy with the Syslog collector and appropriate processing policy.
- Assign the policy to the device.
- Add the dashboard.
Screenshot
Supported Devices
The supported devices of Free Radius with LogPoint in this configuration are:
- Free Radius VPN
- Free Radius Server
- Free Radius WLAN
Log Format
Expected Log Format
Key = Value pair space-separated
Log Samples
<139>Sat Jun 1 04:02:21 2013 : Auth: Login incorrect (rlm_ldap: Bind as user failed): [tantom] (from client vpn1-gw port 688128 cli 1.1.1.1)
tantom -> johndoe
<139>Fri Sep 11 13:13:34 2015 User-Name = "tobper" NAS-Port = 52908032 Service-Type = Framed-User Framed-Protocol = PPP Framed-IP-Address = 1.1.1.1 Class = 0x4f553d697463 Called-Station-Id = "1.1.1.2" Calling-Station-Id = "1.1.1.3" Acct-Status-Type = Start Acct-Delay-Time = 0 Acct-Session-Id = "AF71C8F7" Acct-Authentic = RADIUS NAS-Port-Type = Virtual Tunnel-Client-Endpoint:0 = "1.1.1.4" Vendor-3076-Attr-146 = 0x44656661756c7457454256504e47726f7570 Vendor-3076-Attr-150 = 0x00000002 Vendor-3076-Attr-151 = 0x00000001 Vendor-3076-Attr-152 = 0x00000003 NAS-IP-Address = 1.1.1.5 Client-IP-Address = 1.1.1.6 Acct-Unique-Session-Id = "b06a4bccebe7c953" Stripped-User-Name = "tobper" Realm = "NULL" Timestamp = 1441970014
tobper -> johndoe
To export data to LogPoint, use Syslog collector on port 514 on the LogPoint server.
Support
If you have any queries or require assistance, please feel free to contact our support team:
Email: servicedesk@logpoint.com
Phone: +45 7060 6100
