General Description
The RedSocks application normalizes RedSocks events and enables you to analyze the data using reports, alerts, and pre-set dashboard views. You can further customize the dashboard and searches to perform in-depth analysis.
Release Details
|
Fields |
Details |
|---|---|
|
Name |
RedSocks |
|
Version |
5.0.1 |
|
Supported On |
LogPoint v6.7.0 and later |
|
Release Date |
2020-05-14 |
| Document Date |
2020-05-14 |
| Download | |
| SHA256 |
955da2491325c0c5187d2a3e355dd902fb3cbac8057141039e3b72418c7a995c |
Package Details
The application consists of the following components:
-
Dashboard Package
- LP_RedSocks
-
Report Package
- LP_RedSocks
-
Alert Packages
- LP_RedSocks Bad Neighborhood Detection
- LP_RedSocks Backdoor Connection
- LP_RedSocks FileSharing using 4Shared
- LP_RedSocks FileSharing using WeTransfer
- LP_RedSocks FileSharing using PicoFile
- LP_RedSocks FileSharing using Torrent
- LP_RedSocks Ransomware Connection
- LP_RedSocks Blacklist URL Detection
- LP_RedSocks FileSharing using FileHippo
- LP_RedSocks Tor Connection
- LP_RedSocks Trojan Connection
- LP_RedSocks Sinkhole Detection
-
Normalization Package
- LP_RedSocks
-
Search Template
- LP_RedSocks
-
Compiled Normalizer
- RedSocksCEFCompiledNormalizer
Enhancement
A minor update has been done in the application’s normalizer for better signature handling.
Screenshots
Installation
Follow these steps to install the RedSocks v5.0.1 application:
- Download the RedSocks package from the Download section above.
- Add RedSocks as the required device in LogPoint.
- Create a collection policy with the Syslog collector and appropriate processing policy.
- Assign the policy to the device.
- Add the dashboard.
Supported Device
The supported device of RedSocks with LogPoint in this configuration is:
- Redsocks v3.7.0 alpha1
Log Format
Expected Log Format
<Key>:<Value> separated by comma delimiter
Log Samples
<10>[RedSocks alert] 1.1.1.1:49164 > 192.168.xx.xx:443/TCP, source MAC address: xx:xx:xx:xx:xx:xx, destination hostname: xyz.com, exporter IP address: ::xxxx:xx.x.x.xx, observation domain ID: 1, time: 2017-0e8-31 09:30:30, description: RSxxx - Access Network - abc, category: Bad Hood, threat level: 3
<10>[RedSocks alert] 1.1.1.1:33430 > 3.x.x.x:30001/TCP, source MAC address: xx:xx:xx:xx:xx:xx, destination hostname: abc.net, exporter IP address: ::xxxx:xx.x.x.xx, observation domain ID: 2, time: 2017-07-25 09:03:50, description: RSxxx - Malware Connecting IP, category: Controller, threat level: 1
To export data to LogPoint, use Syslog collector on port 514 on the LogPoint server.
Release Details
|
Fields |
Details |
|---|---|
|
Name |
RedSocks |
|
Version |
3.3.0 |
|
Supported On |
LogPoint v6.0.0 to v6.6.6 |
|
Release Date |
2020-xx-xx |
| Document Date |
2020-xx-xx |
| Download | |
| SHA256 |
3ba01fc2ce25ea7fb41553ea7ce2c40a2c66ce882997990bc14e51fe1f018da1 |
Package Details
The application consists of the following components:
-
Dashboard Package
- LP_RedSocks
-
Report Package
- LP_RedSocks
-
Alert Packages
- LP_RedSocks Bad Neighborhood Detection
- LP_RedSocks Backdoor Connection
- LP_RedSocks FileSharing using 4Shared
- LP_RedSocks FileSharing using WeTransfer
- LP_RedSocks FileSharing using PicoFile
- LP_RedSocks FileSharing using Torrent
- LP_RedSocks Ransomware Connection
- LP_RedSocks Blacklist URL Detection
- LP_RedSocks FileSharing using FileHippo
- LP_RedSocks Tor Connection
- LP_RedSocks Trojan Connection
- LP_RedSocks Sinkhole Detection
-
Normalization Package
- LP_RedSocks
-
Search Template
- LP_RedSocks
-
Compiled Normalizer
- RedSocksCEFCompiledNormalizer
Enhancement
A minor update has been done in the application’s normalizer for better signature handling.
Screenshots
Installation
Follow these steps to install the RedSocks v3.3.0 application:
- Download the RedSocks package from the Download section above.
- Add RedSocks as the required device in LogPoint.
- Create a collection policy with the Syslog collector and appropriate processing policy.
- Assign the policy to the device.
- Add the dashboard.
Supported Device
The supported device of RedSocks with LogPoint in this configuration is:
- Redsocks v3.7.0 alpha1
Log Format
Expected Log Format
<Key>:<Value> separated by comma delimiter
Log Samples
<10>[RedSocks alert] 1.1.1.1:49164 > 192.168.xx.xx:443/TCP, source MAC address: xx:xx:xx:xx:xx:xx, destination hostname: xyz.com, exporter IP address: ::xxxx:xx.x.x.xx, observation domain ID: 1, time: 2017-0e8-31 09:30:30, description: RSxxx - Access Network - abc, category: Bad Hood, threat level: 3
<10>[RedSocks alert] 1.1.1.1:33430 > 3.x.x.x:30001/TCP, source MAC address: xx:xx:xx:xx:xx:xx, destination hostname: abc.net, exporter IP address: ::xxxx:xx.x.x.xx, observation domain ID: 2, time: 2017-07-25 09:03:50, description: RSxxx - Malware Connecting IP, category: Controller, threat level: 1
To export data to LogPoint, use Syslog collector on port 514 on the LogPoint server.
