Lenovo

Release Details

Package Details

The application consist of the following components:

1. Dashboard Package

   • LP_Lenovo IMM
2. Normalization Package

   • LP_Lenovo IMM

Enhancement

A minor update has been done in the application’s normalizer for better signature handling.

General Description

The Lenovo application normalizes Lenovo IMM events and enables you to analyze Lenovo IMM data using pre-set dashboard views. You can further customize the dashboard and searches to perform in-depth analysis.

Installation

Follow these steps to install the Lenovo v5.0.0 plugin:

1. Download the Lenovo package from the Download section above.
2. Add the required Lenovo as a device in LogPoint.
3. Create a collection policy with the Syslog collector and appropriate processing policy.
4. Assign the policy to the device.
5. Add the dashboard.

Supported Version

The supported version of Lenovo with LogPoint in this configuration are:

• Lenovo Storage V3700 V2/V5030 Series

Configuration Of Sources

Log Samples

<14>  Server MTM: 1234XYZ     Alert Text: Remote Control session started by user abc in single-user mode.     Type of Alert: System - Remote Login  Severity: 4 Date(m/d/y): 08/08/2016 Time(h:m:s): 02:01:55   Contact: xyz Location: HVH      IMM Text ID: XYZ-IMM    IMM Serial Number: XXXXX      IMM UUID:ABxxxxxxxxxxxxxx   Event ID: 4000009d00000000      Serviceable Event Indicator: Not Serviceable    FRU list: Not available Room ID: HX2      Rack ID: HV.xx.xxx      Lowest U-position: 41   Blade Bay: Not available      Test Alert: no    Auxiliary Data: Not available Common Event ID: Not available     Event Type: 0     Report Chain: Not available

To export data to LogPoint use Syslog collector on port 514 on the LogPoint server.

Support

If you have any queries or require assistance, please feel free to contact our support team:

Email:             servicedesk@logpoint.com

Phone:           +45 7060 6100

Best regards,
