DarkTrace
In today's threat landscape, SIEM alone lacks the capability to identify emerging threats or incidents that bypass traditional defenses or are active within your network. Combining SIEM with DarkTrace enhances its value by providing real-time monitoring and detection of threats over raw network traffic.
Package Details
DarkTrace components:
-
Dashboard Package
- LP_Darktrace
-
Compiled Normalizer
- DarkTraceNormalizer
Enhancement
Description | Issue ID | Reference ID |
---|---|---|
Added Syslog Collector based Darktrace log source template, simplifying the log source configuration process. To learn more, go to Creating Log Source via a Template. |
KB-23951 |
- |
Installation
To install DarkTrace:- Download the .pak file from the Download link above.
- Go to Settings >> System Settings from the navigation bar and click Applications.
- Click Import.
- Browse to the downloaded .pak file.
- Click Upload.
Past Release
DarkTrace v5.1.0
Supported On: Logpoint v6.7.0 and later
Download: DarkTrace_5.1.0.pak
SHA256: 3c18a076eb0d63293d6c551b37809cebf33fc51c9c3566716a1446359f4bed8d
Bug Fix
Description
|
Issue ID
|
Zendesk Support ID
|
---|---|---|
An issue in the compiled normalizer DarkTraceNormalizer where some DarkTrace breach logs were not normalized. | 12652 | 53589, 56432 |
Supported Version
Logpoint supports all versions of DarkTrace with the JSON format log.
Log Format
Expected Log Format
JSON log (Key:Value format)
Log Samples
<165>Aug 30 12:03:51 xx.x.x.xxx darktrace {"pbid":xxxxx,"pid":xxx,"time":1567166631000,"timestamp":"2019-08-30 12:03:51","creationTime":1567166631000,"creationTimestamp":"2019-08-30 12:03:51","name":"System::System","components":[3486],"didRestrictions":[],"didExclusions":[],"throttle":10,"sharedEndpoints":false,"interval":0,"sequenced":true,
"active":true,"retired":false,"state":"New","commentCount":0,
"triggeredComponents":[{"time":1567166630000,"timestamp":"2019-08-30 12:03:50","cbid":xxxxxx,"cid":xxxx,"chid":xxxx,"size":1,"threshold":0,"interval":3600,"logic":{"data":{"left":"A","operator":"AND","right":{"left":"B","operator":"AND","right":"C"}},"version":"v0.1"},"metric":{"mlid":xxx,"name":"dtsystem","label":"System"},"device":{"did":-1},"triggeredFilters":[{"cfid":xxxxx,"id":"A","filterType":"System message","comparatorType":"is not","arguments":{"value":"Subnet size change"},"triggeringValue":"New subnet detected"},{"cfid":xxxxx,"id":"B","filterType":"Event details","comparatorType":"does not contain","arguments":{"value":"analyze credential ignore list"},"triggeringValue":"New subnet xx.xxx.x.x/xx"},{"cfid":xxxxx,"id":"C","filterType":"System message","comparatorType":"is not","arguments":{"value":"Device model change"},"triggeringValue":"New subnet detected"},{"cfid":xxxxx,"id":"d1","filterType":"System message","comparatorType":"display","arguments":{},"triggeringValue":"New subnet detected"},{"cfid":xxxxxx,"id":"xx","filterType":"Event details","comparatorType":"display","arguments":{},"triggeringValue":"New subnet xx.xxx.x.x/xx"}]}]
<165>1 2021-01-07T09:40:42+00:00 10.10.10.10 darktrace - - - {"breachUrl":"","device":{"ip":"1.2.3.4","hostname":"abc.com","macaddress":"xx:xx:xx:xx:xx:xx","vendor":"Test Vendor","label":"Test Device"},"pbid":123,"score":1,"model":{"description":"Test model used for testing alerting configuration.","created":{"by":"System"},"edited":{"by":"Nobody"},"name":"Unrestricted Test Model","priority":5},"triggeredComponents":[{"metric":{"label":"Test Metric"},"triggeredFilters":[{"comparatorType":"display","filterType":"Test Metric Filter","trigger":{"value":"Test filter value"}}]}],"creationTime":1610012442097,"time":1610012442097}
Support
If you have any questions or require assistance, create a support ticket.
