The application consist of the following components:

1. Normalization Package
   • LP_PRTG

Installation

Follow these steps to install the PRTG v5.0.0 application:

1. Download the PRTG package from the Download section above.
2. Add the required PRTG server as a device in LogPoint.
3. Create a collection policy with the Syslog collector and an appropriate processing policy.
4. Assign the policy to the device.

Supported Device

The device supported by the PRTG with LogPoint in this configuration is:

• PRTG

Log Format

PRTG

Expected Log Format

Key : Value

Log Samples

188>Mar 4 09:46:32 SE-PRTG-SOL-01 PRTG: #device:xxx.xxx.xxx.xx ABC M401dne name:xxxxx status:Warning (was: Down Partial) message:Request timed out (ICMP error # 11010) lastdown:2016-03-04 07:50:51 [1 h 55 m ago] lastcheck:2016-03-04 09:46:31 [0 s ago] host:xxx.xxx.xx.xx deviceid:00000 down:##

<188>Feb 24 12:37:01 SE-PRTG-SOL-01 PRTG: #device:logpointtest.np xxxxxxxxx Webpayadmin name:xxxxxxxx status:Warning message:OK lastdown:2015-10-22 23:24:07 [124 d ago] lastcheck:2016-02-24 12:30:38 [6 m 22 s ago] host:xxx.xxx.xxx.xx deviceid:xxxxxxx down:##

To export data to LogPoint, use the Syslog collector on port 514 of the LogPoint server.
