The application consist of the following components:

1. Normalization Package
   • LP_HAProxy

Installation

Follow these steps to install the HAProxy v5.0.0 application:

1. Download the HAProxy package from the Download section above.
2. Add the required HAProxy server as a device in LogPoint.
3. Create a collection policy with the Syslog collector and an appropriate processing policy.
4. Assign the policy to the device.

Supported Device

The device supported by the HAProxy with LogPoint in this configuration is:

• HA-Proxy v1.5.14

Log Format

HAProxy

Expected Log Format

log-format %ci:%cp\ [%t]\ %ft\ %b/%s\ %Tq/%Tw/%Tc/%Tr/%Tt\ %ST\ %B\ %CC\ %CS\ %tsc\ %ac/%fc/%bc/%sc/%rc\ %sq/%bq\ %hr\ %hs\{%sslv/%sslc/%[ssl_fc_sni]}

Log Sample

<134>Jan 16 08:36:31 xxxxx haproxy[1087]: xxx.xxx.x.xxx:41439 [16/Jan/2018:08:36:31.245] EXCHANGE~ LOGPOINT/CIM-MAIL-01 0/0/3/74/77 200 877 - - ---- 273/257/116/116/0 0/0 "POST /xxxxx?Cmd=Ping&User=xxxxx&DeviceId=xxxxx&DeviceType=xxxxxxxxxxxxx HTTP/1.1"

To export data to LogPoint, use the Syslog collector on port 514 of the LogPoint server.
